V517-The first-generation mass-produced 5G RedCap Internet of Things chip platform.

V517

The first-generation mass-produced 5G RedCap Internet of Things chip platform.

Built based on Release 17 technology and Unisoc's mature, stable and mass-produced 5G platforms, it effectively strikes a balance between low complexity and high performance, fully meets the communication and networking requirements at different stages of 5G development, expands more application scenarios, and brings consumers a more balanced connection experience.

Core Features:

Peak Rate:Downlink (DL) - 226Mbps, Uplink (UL) - 120Mbps

Dual-mode adaptation, fully compatible with 5G RedCap and 4G networks

Bandwidth FR1: 20MHz

Simplified design with 1T2R dual antennas, reducing the cost of terminals

Voice Calling: Voice over New Radio (VoNR) / Voice over Long-Term Evolution (VoLTE)

Support for 5G industry-specific features: 5G Local Area Network (5G LAN), network slicing, high-precision timing

Support for UE energy-saving technologies such as Connected Discontinuous Reception (C-DRX), reducing the overall energy consumption of terminals

Application Scenarios:

Based on Unisoc's mature 5G platform, the RedCap V517 will assist module and terminal customers in rapidly and efficiently developing RedCap products based on Release 17. It can seamlessly adapt to existing 5G industrial routers, industrial gateways, high-definition network video IPCs, intelligent power terminals, entry-level Mobile Broadband (MBB) terminals and expand more 5G vertical application scenarios. Moreover, it effectively accelerates the switch from LTE CAT4 terminal applications to 5G terminal applications.

5G NR SA	N1/N3/N5/N8/N28/N41/N78/N79
LTE-FDD	B1/B3/B5/B8
LTE-TDD	B34/B38/B39/B40/B41
