V510

The Globally Mass-produced 5G Baseband Chip Platform

V510 is UNISOC's globally mass-produced 5G baseband chip platform, which supports 2G/3G/4G/5G network, SA and NSA dual modes, and fully meets different communication and networking needs during the 5G development stage. Moreover, it supports various products, including smartphones, household CPE, MiFi, and IoT terminals, and can be widely used in different scenarios to provide seamless 5G experience to global customers.

Full-Netcom

Single-chip supports TDD NR/FDD NR/FDD-LTE/TDD-LTE/TD-SCDMA/WCDMA/GSM

Supports Sub-6GHz，n78/n41/n79/n1/n28以及n77/n3/n8/n20 and other global mainstream frequency bands

Supports VoNR technology and VoLTE in 5G SA mode

5G Dual-mode

5G NSA and SA dual-mode network

5G downlink rate up to 2.3Gbps and uplink rate up to 1.15Gbps

In the LTE network environment, the downlink rate up to Cat12 600Mbps and the uplink rate up to Cat13 150Mbps

Industrial Grade

Working environment temperature -40℃ ~ +85℃; can be widely applied to intelligent energy, IoV, industrial IoT, telemedicine, intelligent education, HD video, smart city, home entertainment and other vertical industries

Supports Wi-Fi 5 and Wi-Fi 6 solutions

Rich interfaces like PCIE 2.0/USB 3.0/SDIO 3.0/OTG/UART/SPI/I2S/I2C/GPIO and so on; can be adapted in various industry terminals

Processor

CPU	Dual Core
Max CPU Frequency	1.35GHz
Cores	Dual
Process	12nm

Interface

USB	USB 3.0
PCIE	PCIE Gen2.0
eMMC	eMMC5.1
SDIO	SDI0 3.0

Memory

Memory Type	LPDDR4/X
Max DDR Frequency	1866MHz

Communication

Cellular	3GPP Rel.15
	TDD NR/FDD NR/FDD-LTE/TDD-LTE
	TD-SCDMA/WCDMA/GSM/GPRS/EDGE
5G NR	Sub-6GHz
	DL 2Gbps/UL 1Gbps
	NSA & SA
	SUL
	HPUE
LTE-A	Cat12 DL, Cat13 UL, 3CC DL, 2CC UL,
	600Mbps DL, 150Mbps UL
