W517

4G AI Smartwear Platform

W517 adopts the 4-core processor and has the advantages of high performance and low power consumption. It is UNISOC's flagship 4G AI smartwatch platform, with strong AI performance that can provide more diverse AI application scenarios, as well as All-Netcom. In addition, the chipsets have been reduced to 3. W517 also employs EPOP and supermicro high integration technology, along with a more flexible PCB layout, which makes it 30% optimized compared with previous generation products. Moreover, the 12nm technology is adopted to better balance the performance and power consumption of the platform.

Product Features
Communication

4G All-Netcom

4G+WiFi video call

Supermicro High Integration

High-order EPOP packaging; save the external memory chip area

Supermicro highly integrated 3D SiP technology

Strong Battery Life

SOC: Advanced technology in the wearable field

Modem: Low-power smart network search optimization strategy; remote RRC intelligent control technology

OS: Standby energy-saving and heartbeat control technology

Memory: support LPDDR4X; 7% reduction in dynamic power consumption

AI

AI single-microphone smart denoise; non-noise call

AI video anti-shake; more stable and high-quality video effects

AI face recognition, secure and convenient authentication and payment

AI dual-camera video call; more secure guard

Product Parameters
Processor
CPU

1*A75@2.0GHz3*A55@ 1.8GHz

Max CPU Frequency

2.0GHz

Cores

4

Process

12nm

Graphics
GPU

IMG8300 @ 800MHz

Display Resolution

HD+

Video Decode

1080P @ 30fps, H.264/H.265

Video Encode

1080P @ 30fps, H.264/H.265

Memory
Memory Type

LPDDR3/LPDDR4x

Storage Type

eMMC 5.1

Camera
Max Camera lSp

16MP

Capture Fps

30fps

Modem
Cellular

LTE FDD & TDD, WCDMA, CDMA,GSM

LTE Category

LTE Cat4,VOLTE

Connectivity
GNSS

GPS/GLONASS/BEIDOU

Bluetooth

Bluetooth@5.0

Wi-Fi

802.11 b/g/n/ac

Note: The power consumption and security improvement data on this page are from the test data of UNISOC Laboratory. The actual situation may vary slightly depending on the version and test environment.
GNSS/Wi-Fi/Bluetooth/FM：UMW2652
