W377E

High Performance 4G Smart Wearable Platform

W377E has a quad-core Arm Cortex A53 processor, small package size. Multimedia capabilities and AP performance all have major improvements compared to the previous generation. W377E integrates 2G, 3G, 4G, Bluetooth, Wi-Fi and GNSS, flexible PCB layout, and adopts 28nm HPC+ process to better balance the performance and power consumption. W377E has advantages of both high performance and low power consumption, designing for multiple devices such as smartwatches.

Product Features
Android OS,64-bit Systems:

W337 running Android8.1OS provides richer and more diverse APP experience, supports online friend chat, Alipay and other apps, enrich the user experience, and can be upgraded to support 64bit apps.

Communications:

SupportsGSM, WCDMA, LTE Cat.4, field tests conducted in more than 130 countries worldwide.

Performance:

W377E has a quad-core Arm Cortex A53 processor, supports Mali T820 GPU, be able to achieve smooth experience in high-processor load and concurrent scenarios such as video calls.

High Integration、High Flexibility:

Integration of 2G, 3G, 4G, Bluetooth, Wi-Fi, GNSS, LPDDR and NAND, WCN and memory modules can be freely selected, flexible PCB layout, providing customers with more flexible choices.

Product Parameters
CPU

4*A53 @ 1.4GHz

GPU

Mali T820 MP1 @ 600MHz

Camera

13M

Display

VGA@ MIP!

Video Codec

1080P 30fps @ H.264

Memory

eMCP: 32Gb+4Gb or above

Modem

LTE FDD & TDD,WCDMA, GSM

Category

LTE Cat.4, VOLTE

WCN

Wi-Fi 802.11bgn @ 2.4GHz

Bluetooth@ 4.2/GPS/Glonass/Beidou

Process

28nm, HPC+

Package Size

BGA, 9.4mm*9.4mm

MP time

2024 Q2
