W307

The High Performance 4G RTOS Watch Platform

W307 integrates 2G/3G/4G, BT, Wi-Fi, GNSS, built-in LPDDR2, NandFlash watch platform. PCB layout is flexible, and can achieve single-sided board; The 28nm HPC+ technology of TSMC is adopted to better balance the performance and power consumption of the platform. Under the same performance condition, it is better than the competitive products by 30%+.

Product Features
Communication

LTE Cat4/WCDMA/GSM, VoLTE

4G+WiFi HD video call

High Performance, Light System

RTOS lightweight operating system

Low requirements on CPU and Memory resources

High-precision Positioning

Nine fold positioning technology + high-precision positioning SDK+ cloud platform

Sub-meter level positioning solution

Maturity

Field tests conducted in more than 130 countries worldwide, shipment by 200+ operators

Mocor RTOS software platform

High Integration and Low Power Consumption

Integration of 2G/3G/4G, Bluetooth®, Wi-Fi, GNSS, built-in LPDDR2, and NAND Flash

More flexible PCB layout, one-sided board

28nm process HPC+ technology, with 30% more performance

Overall low power consumption

Product Parameters
Processor
CPU

Arm Cortex-A53

Max CPU Frequency

1.1GHz

Cores

Single

Process

28nm HPC+

Graphics
Max Display Resolution

VGA

Video Decode

VGA 30fps H.264,MPEG4, H.263,VP8

Video Encode

VGA 30fps H.264, MPEG4

Memory
Memory Type

LPDDR2

Max Memory Size

SiP LPDDR2 1Gb

Storage Type

SiP Nand Flash 1Gb

Camera
Max Camera lSP

5M

Capture FPS

30fps

Connectivity
Cellular

GSM/WCDMA/TDD-LTE/FDD-LTE

LTE Category

Cat4

GNSS

GPS+Glonass/Beidou

Wi-Fi

b/g/n

Bluetooth

Bluetooth@4.2

FM

Yes
