T7225

High-quality Image with Excellent Performance

T7225 is a new Octa-core LTE mobile platform of UNISOC. It is designed based on DynamIQ's new generation of big.LITTLE architecture. It is equipped with four high-end cameras with more than 100-million pixels, the fifth-generation self-developed image engine Vivimagic solution, and high-definition display processing technology to capture a more real and clear world.

Product Features
Communication

Highly reliable communication module

Global shipment on a large scale

Performance

2 x A75@1.8 GHz+6 x A55@1.8 GHz

High-performance GPU with a new generation of Arm G57 architecture

UFS fast flash interface is supported, enabling more efficient data access


The new generation of 3-core ISP, 14-bit Pipeline and four high-end cameras make it possible to simultaneously process ultra-wide-angle, wide-angle and long-focus image data and realize switchover without delay and accurate image restoration

Self-developed technologies such as AI portrait division, seamless zoom, intelligent picture retouching and scenario detection

Wide color gamut management, adaptive screen brightness, intelligent resolution, blue-ray suppression, etc.

FHD + HD display

Product Parameters
Processor
CPU

2XA75+6XA55

Max CPU Frequency

186HZ

Cores

Octa

process

12nm

Graphics
GPU

Arm Mali G57 1Core @650MHz

Manhattan ES3.014fps

Max Display Resolution

FHD 60fps, HD+ 90Hz

Video Decode

1080p 60fps

Video Encode

1080p 60fps

Memory
Memory Type

LPDDRAX

Max Memory Size

LPDDR4X@1600MHz

Storage Type

eMMC 5.1/UF52.1/UFS2.2

Camera
Camera

Up to 108M, 32MP ZSL

Dual Cameras 16MP+8MP

Connectivity
FM

yes

Cellular

TDD-LTE / FDD-LTE / TD-SCDMA/ WCDMA /GSM

Category

LTE Cat 7

GNSS

Gps/Glonass/Beidou/GalileoA-GNSS

support four-mode positioning

Wi-Fi

802.11 ac/b/g/n (softAP)

Bluetooth

Bluetooth*5.2

Al

N/A

Note: The power consumption and security improvement data on this page are from the test data of UNISOC Laboratory. The actual situation may vary slightly depending on the version and test environment.
GNSS/Wi-Fi/Bluetooth/FM：UMW2651 or UMW2652 or UMW2631
