T7200

Unmatched Performance and Connectivity,Supports All Kinds of Networks

T7200 is designed to support speedy downloads and uploads, stunning graphics and photos, and power-saving performance. Based on advanced 12nm processing technology, T7200 lets users do more, faster, thus giving an unparalleled smartphone experience.

Product Features
Connectivity

Highly reliable communication module

To be sold on a global scale

Performance

2 x A75@1.6GHz + 6 x A55@1.6GHz

GPU features a new generation of Arm G57 architecture

UFS 2.0, enabling more efficient data access

Graphics

The three-core ISP, 14-bit Pipeline and four high-end cameras make it possible to simultaneously process ultra-wide-angle, wide-angle, and long-focus image data, realize switchover without delay, and restore images accurately;

Features self-developed technologies such as AI portrait division, seamless zoom, intelligent picture retouching, and scenario detection

Wide color gamut management, adaptive screen brightness, intelligent resolution, blue-ray suppression.

Product Parameters
Processor
CPU

2XA75+ 6XA55

Max CPU frequency

1.6GHz

Core

Octa

Graphics
GPU

Arm Mali G57 1Core @650MHz

Manhattan ES3.0 14fps

Max Display Resolution

H0+90Hz

Video Decode

1080p 60fps

Video Encode

1080p 60fps

Memory
Memory Type

LPDDR4X

Max Memory Size

LPDDR4x@1600MHz

Storage Type

eMMC 5.1/UFS2.1/UFS2.2

Camera
Camera

up to 24M

Dual Cameras 16+8MP

Connectivity
Cellular Category

TDD-LTE / FDD-LTE / TD-SCDMA / WCDMA / GSM

Category

LTE Cat 7

GNSS

Support GPS/Glonass/Beidou/GalileoA-GNSS

support four-mode positioning

Wi-Fi

802.11 ac/b/g/n (softAP)

Bluetooth

Bluetooth®5.0

FM

yes

Note: The power consumption and security improvement data on this page are from the test data of UNISOC Laboratory. The actual situation may vary slightly depending on the version and test environment.
GNSS/Wi-Fi/Bluetooth/FM:UMW2651 or UMW2652 or UMW2631
