Advanced 28 nm HPC+ technology

8-core A55 CPU architecture with a dominant frequency of up to 1.6 GHz

CPU computing power of up to 30K+ DMIPS

Powerful GPU IMG 8322 @ 550 MHz

High-speed LPDDR4X

High-speed eMMC 5.1

High level of integration: Integrated with WCN

Android 10/12

Low power consumption, excellent decoupling, and all-scenario communication

Supports T-Box applications such as networked communication, big data, remote control, and OTA

High-speed USB 2.0. OTG

supported

Working with Marlin3E to support USB HUB

3 IISes

7 IIC interfaces

5 UART interfaces

Supports 4 SPIs

Built-in 3 ISPs and 3 CSI interfaces. 4 x 720P camera inputs are supported through Serdes expansion.

Supports 16-megapixel high-definition cameras

Supports HDR, 3DNR, automatic AE, and other AI algorithms, resulting in clearer images in low-light conditions. Supports AVM and DVR

Supports multiple codec formats,such as H.264, H.265, VP8, VP9, and MPEG4. Codec for resolution up to 1080p @ 30 fps

4lane MIPI DSI interface, expandable to

support dual-screen heterogeneous displays

Supports FHD 60 fps

Dual camera upgrade, higher picture, and lower power consumption

4G, 3G, 2G

2.4/5GHz WiFi, 802.11b/g/n/ac. Faster

speed

GNSS (Beidou, GPS, Glonass). More accurate positioning

Bluetooth 5.1
