A7870 Series-Flagship Smart Cockpit Solution Platform

A7870 Series

Flagship Smart Cockpit Solution Platform

The A7870 series is an automotive-grade smart cockpit processor chip independently developed by UNISOC that offers advantages such as high performance, low power consumption, and a high level of integration. It complies with the AEC - Q100 automotive-grade process system and guarantees suitability for on-board ambient temperatures between -40 and 85°C. Due to its NATT 4 core @ 850 MHz configuration, the GPU provides excellent support for high-definition rendering requirements in commonly encountered cockpit or cockpit parking scenarios. The A7870 series features a built-in high-performance NPU with up to 8 TOPS AI computing power, providing powerful AI capabilities for cockpit parking, cockpit driving, etc.

5G-based unmatched computing power

CPU：1 * A76 @ 2.7GHz + 3 * A76 @ 2.3GHz + 4 * A55 @ 2.1 GHz，93k DMIPS

GPU：NATT 4 core @850Mhz，486.4 GFLOPS

NPU： IMG AX3596 @8 TOPS

5G SA&NSA 3GPP R16；TDD+FDD 5G 2CC

SA：3.25GbpsDL 1.25Gbps UL；

NSA：3.3GbpsDL 1.45Gbps UL；

LTE：Cat15DL，2CC，800Mbps/Cat.18UL；200Mbps；

2/3G：WCDMA；GSM

Plenty of interfaces

MIPI DSI 4lane*1, DP1.4, and CSI 4lane*4

UFS 3.1, PCIE 3.0, and I2S*6

6 HD screen outputs + 12 HD camera inputs

Automotive-grade certification ensuring security and reliability

Support for rigorous AEC-Q100 automotive-grade certification

Complete adaptable cockpit software solutions

Integrated solutions: Smart cockpit/cockpit parking in one + T-Box all-in-one machine

One chip for multiple cross-domain systems: QNX, Linux, Android Automotive, and Virtual Machine Multi-Baseline

Built-in iSE financial-grade security solution

Top-notch multimedia capability

QHD+/60Hz super screen dominator

Recording and playback of ultra-high-definition 4K videos across all channels

Multi-register voice interaction

ISP	48M@30fps(lane4+4+4+4/4+4+2+2+2+2)
VDSP	2 TOPS
Display	6 screens,DSl(33601440) @ 60 fps, DP(38402160) @ 60 fps
Video Coding	4K*2K @ 30 fps, 10 bit, H.264/H.265
Video Decoding	4K*2K @ 30 fps, 10 bit, H.264/H.265

RAM	IPDDR 4/4x@ 2133 Mhz up to 32 GB
ROM	eMMC 5.1,UFS3.0

System	3GPP, NSA, SA, VONR, LTE TDD&FDD, WCDMA, GSM
Capacity	LTE: DL Cat.7 & UL Cat.13; 5G NR
