7865

High-performance 4G intelligent solutions.

The 7865 is a high-end 8-core 4G SoC with enhanced performance. It adopts an architecture of 2*A75@2.2GHz + 6*A55@1.8GHz. Its GPU has a frequency of 850MHz. The display capability has been improved compared to the previous generation. It can support a high refresh rate of FHD+@90fps, support taking photos with hundreds of millions of pixels, and support Wi-Fi5/Bluetooth 5.2/GNSS, USB HUB, UFS2.2 storage interface, etc. It also supports LTE CAT.7 and L+L DSDS (Dual Sim Dual Standby). The operating system supports Android 14 and will continue to evolve. This product is applicable to various scenarios such as industrial handheld devices, aftermarket vehicle installations, video recognition, and multimedia terminals.

Product Features
High maturity

It adopts a mature 12nm manufacturing process, with over 100 million units shipped. It has excellent power consumption performance and chip quality. Its shipments cover 133 countries around the world and have passed the shipment certifications of over 260 operators globally, possessing a stable LTE CAT.7 communication capability.

High performance

It supports an 8-core architecture of 2A75@2.2GHz + 6A55@1.8GHz, features the mainstream ARM Mali-G57 @850MHz GPU performance, and uses LPDDR4x@1866MHz, leading in performance among products in the same category.

In terms of display, it supports FHD+@90fps and has features such as wide color gamut management, screen brightness adaptation, intelligent resolution, and blue light suppression.

It supports 3*Camera CSI interfaces, allowing for the simultaneous input of three video streams. It has high-performance encoding and decoding capabilities, supporting single encoding and single decoding at 1080p 60fps, as well as simultaneous encoding and decoding at 1080p 30fps.

In terms of connectivity, it natively supports Wi-Fi 5/Bluetooth 5.0/GNSS.

High extensibility (with abundant external expansion interfaces)

It supports eMMC5.1 and UFS 2.2 high-speed storage interfaces, meeting the needs of customers with small storage capacities as well as the development needs for large-capacity storage. It also has abundant peripheral interfaces.

Life cycle

Starting from Android 14, the Android version will continue to be upgraded in the future, and the life cycle is planned until 2030.

Product Parameters
CPU

2*A75+6*A55 Architecture

GPU

G57 @ 850MHZ

Memory

eMMC 5.1;UFS2.2

LPDDR4x @1866MHz

Modem

LTE Cat7,L+L DSDS

Display

FHD+@90fps

Camera

48MP (megapixels) @ 25fps, with simultaneous input from the Tri-camera

16+16MP,16+8+8MP

Video
Decode

1080p @60fps,H.264/H.265

Encode

1080p @60fps,H.264/H.265

WCN
WIFI5,BT5.0,GNSS

UMW2631

Interface
UART

UARTx7

SDIO

SDIO3.0×3

USB

1xUSB2.0 HUB

SPI

SPl×4

I2C

I2C×8

I2S

I2S(8ch)

MIPI CSI

3×MIPI CSI 4 lane

MIPI DSI

1×MIPI DSI 4 lane

Process

12nm
