7861

Mid-range Android solutions.

The 7861 is a mid-range, cost-effective 8-core 4G SoC with a 12nm manufacturing process. It adopts an 8-core architecture of 2*A75@1.6GHz + 6*A55@1.6GHz. It supports Wi-Fi 5, Bluetooth 5.0, GNSS, USB Hub, UFS2.2 storage interfaces, etc. It also supports LTE Cat.7 and L+L DSDS (Dual Sim Dual Standby), and has strong multimedia capabilities. The operating system supports the Android 12 system and will continue to evolve. It is applicable to industry scenarios such as smart payment, industrial handheld devices, video recognition, and multimedia terminals.

Product Features
High maturity

It adopts a mature 12nm manufacturing process, with over 100 million units shipped.

It has excellent power consumption performance and chip quality.

It has undergone field tests globally, covering more than 130 operators in over 100 countries, and has a stable LTE Cat.7 communication capability.

High performance

It adopts an 8-core architecture of 2A75@1.6GHz + 6A55@1.6GHz.

It has 3*Camera CSI interfaces, a Tri-core ISP (Image Signal Processor), and supports the simultaneous input of three video streams.

It supports encoding and decoding at 1080P 60fps.

It natively supports Wi-Fi 5/Bluetooth 5.0/GNSS.

High extensibility (abundant external expansion interfaces)

It supports the maximum LCD resolution of FHD+@60fps.

It supports the UFS 2.2 high-speed storage interface, meeting the development needs for large-capacity storage in the future.

It has abundant peripheral interfaces.

Life cycle

Starting from Android 12 (which supports a running environment with a small memory of 1GB + 8GB), the Android version will continue to be upgraded. The life cycle is planned until 2030.

It is hardware-compatible with the 7863 within the 12nm product family and shares the same Android software baseline, which facilitates the investment of minimal research and development resources and enables the combination of products in different grades as well as the inheritance of requirements.

Product Parameters
CPU

It adopts an 8-core architecture of 2*A75@1.6GHz + 6*A55@1.6GHz.

GPU

Arm®Mali™G57 @650MHz

Memory

eMMC 5.1;UFS2.2

LPDDR4x@ 1866MHz

Modem

LTE Cat7, L+L DSDS

Display

FHD+60fps

Camera

48MP@ 25fps,Dual Cameras 16+16MP.

Tri-core ISP 16+8+8MP

Video
Decode

1080p @60fps, H.264/H.265

Encode

1080p@60fps, H.264/H.265

WCN
WIFI5,BT5.0,GNSS

UMW2631

Interface
UART

UART×7

SDIO

SDIO3.0×3

USB

1×USB2.0 HUB

SPI

SPl×4

I2C

I2Cx8

I2S

I2S(8ch)

MIPI CSI

3×MIPI CSl 4 lane

MIPI DSI

1×MIPI DSI 4 lane

Process

12nm
