7863

A High-end Smart Solution for the 4G Industry

7863 is a high-performance 8-core 4G SoC built on a 12nm process, featuring a dual-core A75@2.0GHz + 6-core A55@1.8GHz architecture. It supports WiFi 5/Bluetooth 5.0/GNSS, USB 2.0 OTG/HUB, UFS 2.2 storage interface, and more. Boasting strong multimedia capabilities, it also supports LTE Cat 7 and L+L DSDS. For the operating system, it is compatible with Android 12 and above, with continuous OS evolution support. This SoC is suitable for industrial scenarios such as industrial handheld work devices and multimedia terminals.

Product Features
Remarkable performance (outperforming similar products from competitors in benchmark tests)

An octa-core architecture incorporating "2*A75@2GHz+6*A55@1.8GHz"

G57@750MHz image processor

High-speed 2G/3G/4G Cat7 cellular communication modem

Native support for WIFI 5/Bluetooth 5.0/GNSS

48MP@25fps, Dual Cameras 16+16MP, Tri-Core ISP 16+8+8MP

The 12nm process enables exceptional power efficiency during multi-background operations.

Robust security (the proprietary TEE and SecureCamera protect facial recognition applications)

The UNISOC TEE security solution and high-level encryption algorithms (SCA-certified algorithms SM2/3/4) ensure all-round security protection for smart devices.

TOS customization is supported.

Impressive maturity (backed by 20 years of large-scale field test experience)

Extensive field test presence across 100+ countries with 130+ operators worldwide

The two-year mass production achieved global shipments surpassing tens of millions.

Remarkable scalability (different selection of external expansion interfaces)

Capable of handling LCD resolutions up to FHD+ @60FPS

Offering support for UFS 2.2 high-speed storage interfaces to cater to the future needs of large-capacity storage

Diverse array of peripheral interfaces

Tailor-made software and hardware

Compatible with Android 12 and capable of providing support to Android 16 in future iterations

A future-proof upgrade solution tailored for the industry's handheld devices over the next three years

Open-source operating systems and their ecosystems are supported.

Product Parameters
CPU

2*A75+6*A55 Architecture

GPU

G57@750MHZ

Memory

eMMC5.1;UFS2.2

LPDDR4x @1866MHz

Modem

LTECat7,L+L DSDS

Display

FHD+60fps

Camera

48 megapixels (MP) @ 25 frames per second (fps), with simultaneous input from the Tri-camera

16+16MP,Tri-core ISP 16+8+8MP

Video
Decode

1080p @60fps, H.264/H.265

Encode

1080p @60fps, H.264/H.265

WCN
WIFI5,BT5.0,GNSS

UMW2631

Interface
UART

UARTx7

SDIO

SDI03.0×3

USB

1xUSB2.0 HUB

SPI

SPIx4

I2C

I2C×8

I2S

i2S(8ch)

MIPI CSI

3xMIPI CSI 4 lane

MIPI DSI

1xMIPI DSI 4 lane

Process

12nm
