M6780

8K Ultra HD intelligent computing platform with outstanding multimedia capabilities.

A high-performance chip platform with powerful intelligent computing capabilities, specially designed for 8K 60Hz ultra-high-definition display. It combines MEMC, multi-core CPU and GPU, as well as many AI, image, audio and video enhancement processing technologies such as NPU, VDSP and ADSP, helping the industrial ecosystem to create competitive terminal products.

Product Features
Performance

CPU：Cortex-A76*2 + A55*2

GPU：Arm Mali Natt 4 cores

NPU：Up to 6TOPs

DSP：VDSP + Dual core ADSP

Audio

Full-link audio quality improvement solutions: The audio track supports Dolby Atmos, and also supports AI-AQ (AI Audio Quality) AI sound effects, with rich sound effects + sound field calibration.

AI-Voice far-field voice + built-in voice assistant.

Dual-core HiFi5 high-computing-power open Audio DSP (Digital Signal Processor) platform.

Display

Support hardware backlight partitioning Local dimming.

Support mainstream 8K decoding standards such as H.265/VP9/AV1/H.264.

Support Full HDR: Dolby Vision/ HDR10/ HDR10+/ HLG.

Support AI super resolution (AI-SR).

Support AI image quality enhancement (AI-PQ).

Support 4K 120fps MEMC (Motion Estimation and Motion Compensation) function.

VX1 up to 8K@60fps / 4K@120fps.

TCON 4K@120fps.

A mature PQ (Picture Quality) processing engine - including Sharpness, DCI, NR, etc.

Multiple applications

4K UI

Flexible support for software decoding formats

4K video rotation

Support for Active VRR (Variable Refresh Rate) based on GPU rendering

AI capabilities (AI-SR: AI Super Resolution, AI-PQ: AI Picture Quality, AI-AQ: AI Audio Quality, AI-Voice: AI Voice)

Secure protection for DRM (Digital Rights Management) content

Support for global D-mod

Three HDMI2.1 ports, supporting the transmission of 8K content.

Product Parameters
Processor
CPU

Arm Cortex-A76*2+A55*2

GPU

Arm Mali Natt 4 cores

NPU

Up to 6.4 TOPs

DSP

VDSP+Dual core ADSP

Memory
RAM

96 bit LPDDR4 @ 1866Mhz

64bit DDR4 @ 1600MHz

ROM

eMMC5.1

Interface

HDMI2.1*3

USB3.0*2+USB2.0 w/OTG support*2

Gigabiy Ethernet MAC;PCIE2.0

Application

4K UI

Flexible support for software decoding formats

4K video rotation

Support for Active VRR (Variable Refresh Rate) based on GPU rendering

AI capabilities (AI-SR: AI Super Resolution, AI-PQ: AI Picture Quality, AI-AQ: AI Audio Quality, AI-Voice: AI Voice)

Secure protection for DRM (Digital Rights Management) content

Support global D-mod

Three HDMI2.1 ports, supporting the transmission of 8K content
