V8850-Cat.1bis single-chip IoT security solution that supports outdoor integrated positioning

V8850

Cat.1bis single-chip IoT security solution that supports outdoor integrated positioning

The V8850 is UNISOC's groundbreaking, secure, and credible chip in the cellular IoT sector, integrating indoor and outdoor positioning for enhanced security and reliability. This chip has been intelligently upgraded based on the previous generation of products. It has the following six features: Higher integration and a smaller footprint; indoor-outdoor integrated positioning; enhanced Open CPU capability; lower power consumption; a wide temperature range for industrial applications; high security and reliability. Therefore, it's appropriate for various industries such as positioning, sharing, payment, monitoring, and industrial control.

Full-fledged R13 Cat.1bis communication

Built upon the well-established and globally verified modem communication protocol stack of 8910DM

Indoor-outdoor integrated positioning supported

GNSS global positioning supported, including GPS, Beidou, Galileo, and Glonass

Wifi-Scan positioning

Proven dual A5 OPENCPU architecture

Plenty of IO interfaces: USB2.0, UARTx6, GPIOx48, ADCx4, LCD, Camera, I2S, etc.

OPENCPU architecture supported; easy customer application migration achieved through virtual AT, dynamic loading, etc.

Ideal for industrial use because of its low power consumption and extensive temperature tolerance

The PSM current is less than 1.5 uA

Wide range of temperatures from -40 to 85°C

High level of integration

Integrated BB/RF/PMIC/GNSS on a single chip; 8.2x8.2 mm small-footprint package

Built-in large memory of 8 MB + 16 MB

Secure and credible

Conventional algorithms RSA/AES/SHA and national cryptographic algorithms SM2/SM3/SM4 are supported.

With the TEE secure execution environment, it's capable of supporting data-secure applications such as blockchain/industrial Internet identification.

Compliant with the Common Criteria for IT Security Evaluation (CC EAL2+); the SCA-certified algorithm level 1 met.
