V8310

LTE Cat.4 Product Platform with Global Wide-Scale Production and Delivery

The V8310 is a highly integrated LTE Cat.4 platform that supports TDD-LTE, FDD-LTE, WCDMA, GSM/GPRS/EDGE. It is intended to provide IoT (Internet of Things) solutions that are cost-effective, low-power, and high-performance

Product Features
V2 Modem

V8310 inherits UNISOC's most mature LTE V2 Modem, with guaranteed power efficiency, performance, and stability. It has been widely deployed in commercial use in over 100 countries and regions around the world, with cumulative shipments exceeding 100 million units.

Temperature Range

The 8310AM operates within a temperature range of -20~60 °C, suitable for consumer applications.

The -8310WT extends its operating temperature range to -40~85 °C meeting industrial specifications for power and other applications.

Operator Certifications

Has passed certification and testing from global mainstream operators such as Voadafone, Orange, Reliance, TRUE, AT&T, Telcel, as well as IoT testing with communication base station manufacturers like Huawei, ZTE, Ericsson, and Nokia.

Rich Interfaces

SDIO 3.0, USB 2.0 FS/HS (USB device and USB host), UART, SPI, I2S, I2C, and (U)SIM*2

Communication Support

Supports dual SIM, dual standby, and dual Volte

Product Parameters
CPU

Cortex-A7

MEMORY

Sip LPDDR2 64MB

SPI/SLC Nand Flash

MODEM

UNISOC V2 Modem

LTE FDD&TDD Cat4, WCDMA, GSM, L+L/双 VoLTE

CLOCK

DXCO 26MHz

PACKAGE

8.lmm*8.1mm, BGA

OS

RTOS

PCB

6HD1-1
