The independently developed generation-5 video or image engine Vivimagic solution, equipped with a brand-new 3-core ISP, enhances the HMI-based on-board video or image entertainment
Interaction. Full HD video recording, all-hardware H.265 codec, system-level integration of Bluetooth 5.0 BLE and Bluetooth hands-free phone (HFP), music playback (A2DP), and support for GPS+Beidou+Glonass and GPS+Galileo+Glonass "three-mode"
Positioning. Enhanced computing power enables more intelligent, personalized, and emotional OBU interaction.
Manufactured with 12 nm technology, this masterpiece has 2 ARM Cortex A75 and 6 ARM Cortex A55 1.8 GHz processors. The CPU works with the Mali G52 GPU to provide higher-quality on-board video or image effects.
The power consumption is reduced by 30% during multi-background operation, contributing to higher stability and reliability.
3 x SDIO 3.0 / USB 2.0 OTG / USB 1.1 /4 x SPI / 4 x I2S / 8 x I2C / 7 x UART
150 + GPIOs
Global field tests and global network access licensing Proven and stable on-board performance is recognized by operators around the world
The 7862ST is capable of operating within the car’s ambient temperature range of -40°C to 85°C.
360 surround view, ADAS (advanced driver assistance system), DMS (driving monitoring system), AR navigation, and other on-board applications
